| Applicable Material | | Cast Iron | Hard Materials | | Grade | TT6080 |
| Application | | Chamfer & Serration | Facing | Inserts | | Maximum Feed per Tooth (fz(max)) | 0.2 mm/tooth |
| Corner Radius (RE) | 1 mm | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 4 mm | Minimum Feed per Tooth (fz(min)) | 0.07 mm/tooth |
| Inscribed Circle Diameter (IC) | 12.7 mm | Measurement Type | Metric |
| Insert Thickness (S) | 5 mm | Body Material | Carbide |
| Coating | AlTiN+TiN | Unit | M |
Product Features
| Family Description | Screw on type size HEXA2MILL insert General type | FamilyName | HNMX 05-MM |
| COO | S.KOREA | BrandName | Taegutec |
Shipping Info
Weight per item
0.0086
Name
Milling Indexable Inserts
FamilyName
HNMX 05-MM
BrandName
Taegutec
